4.5”H Family Motor

Motor drawings

电机参数 Motor Data		电机型号 Motor Model
电机参数 Motor Data		ZD053	ZD036	ZD034	ZD033	ZD054	ZD035	ZD085	ZD010	ZD132
额定功率 Nominal Power	kW	1.2	1.6	2	2	1.2	2.2	2.8	2	3
额定电压 Nominal Voltage	V	12	12	12	12	24	24	24	48	48
环境温度 Environmental Tempeature	°C	-20-40°C	-20-40°C	-20-40°C	-20-40°C	-20-40°C	-20-40°C	-20-40°C	-20-40°C	-20-40°C
空载转速 No-load Speed	Rpm	5500	6200	3800	6200	6000	5500	8200	4800	5200
空载电流 No-load Current	A	35	45	40	50	20	20	25	15	20
额定负载 Nominal Torque	N.m	4.7	6	8	5.4	3	7.5	10	7	8
额定转速 Nominal Speed	Rpm	2400	2650	2300	2586	4500	2600	3000	2850	3800
额定电流 Nominal Current	A	160	200	210	200	85	125	175	70	95
工作制 Duty Cycle	S2	1.2MIN	2MIN	2MIN	7.5MIN	1.2MIN	2MIN	5MIN	2MIN	6MIN
工作制 Duty Cycle	S3	4.5%ED	5%ED	8%ED	20%ED	4.5%ED	5%ED	13%ED	8%ED	10%ED
电机转向 Motor Rotation	CW/CCW	CW	CW	CW	CW	CW	CW	CW	CW	CW
电机噪音 Motor Noise	dBA/1m	72	72	72	72	72	72	72	72	72
电机尺寸 Motor Dimension	L（ mm）	153	174.3	174.3	191.3	153	174.3	206.1	177.5	218.1
电机尺寸 Motor Dimension	D（ mm）	114	114	114	114	114	114	114	114	114
电机重量 Motor Weight	Kg	5.1	7.1	7.6	8.2	5.1	7.1	9.4	7.5	9.4

电机设计 Motor Design		电机型号 Motor Model
电机设计 Motor Design		ZD053	ZD036	ZD034	ZD033	ZD054	ZD035	ZD085	ZD010	ZD132
绝缘等级 Insulation Degree	Class	F	F	F	F	F	F	F	F	F
温控 Thermal Protection	Optional	√	√	√	√	√	√	√	√	√
防水等级 IP Class	Class	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
励磁方式 Excitation	Wound	串励 Series	串励 Series	复励 Compound	串励 Series	复励 Compound	复励 Compound	串励 Series	复励 Compound	复励 Compound
振动 Vibration	mm/S	<2	<2	<2	<2	<2	<2	<2	<2	<2
绝缘强度 Insulation Resistance	MΩ	>10	>10	>10	>10	>10	>10	>10	>10	>10
电机寿命 Motor Endurance	Hrs	400	400	400	800	400	400	800	400	400
