DC Brushed Motor
| 电机参数 Motor Data | 电机型号 Motor Model | |||
|---|---|---|---|---|
| ZD100 | ZD101 | ZD065 | ||
| 额定功率 Nominal Power | kW | 3.3 | 4.5 | 4.5 |
| 额定电压 Nominal Voltage | V | 24 | 24 | 48 |
| 环境温度 Environmental Tempeature | °C | -20-40°C | -20-40°C | -20-40°C |
| 空载转速 No-load Speed | Rpm | 6800 | 7000 | 6800 |
| 空载电流 No-load Current | A | 35 | 40 | 20 |
| 额定负载 Nominal Torque | N.m | 10 | 17 | 17 |
| 额定转速 Nominal Speed | Rpm | 2900 | 2550 | 2550 |
| 额定电流 Nominal Current | A | 160 | 240 | 110 |
| 工作制 Duty Cycle | S2 | 20MIN | 15MIN | 15MIN |
| S3 | 35%ED | 30%ED | 30%ED | |
| 电机转向 Motor Rotation | CW/CCW | CCW | CW | CW |
| 电机噪音 Motor Noise | dBA/1m | 90 | 90 | 90 |
| 电机尺寸 Motor Dimension | L（ mm） | 283 | 283 | 283 |
| D（ mm） | 142 | 142 | 142 | |
| 电机重量 Motor Weight | Kg | 19.5 | 16.8 | 16.8 |
| 电机设计 Motor Design | 电机型号 Motor Model | |||
|---|---|---|---|---|
| ZD100 | ZD101 | ZD065 | ||
| 绝缘等级 Insulation Degree | Class | H | H | H |
| 温控 Thermal Protection | Optional | √ | √ | √ |
| 防水等级 IP Class | Class | IP23 | IP23 | IP23 |
| 励磁方式 Excitation | Wound | 串励 Series | 串励 Series | 串励 Series |
| 振动 Vibration | mm/S | <5 | <5 | <5 |
| 绝缘强度 Insulation Resistance | MΩ | >10 | >10 | >10 |
| 电机寿命 Motor Endurance | Hrs | 800 | 800 | 800 |
