parameter

Engine	yunnei
Tires	8.25-16
Transmission	265
Arm Length	1830mm
Arm width	290mm
Lifting height	3400mm
Exterior Dimension	4600/1310/2130mm
Rated speed	2200（r/min）
Rated load	600kg
Bucket width	1300mm
Bucket capacity	0.4m³
Axles	Isuzu Bridge
Frame articulation	Front 20mm Rear 10mm
Weight	2060kg
Arm thickness	17mm
Unloading height	2400mm
Transmission	turbo transmission
Wheelbase	2100mm
Wheelbase	1100mm
Minimum Ground Clearance	270mm
Center Cylinder Rod Diameter	45mm
Cylinder rod diameter on both sides	35mm
